产品概述

零延迟

HDX & USB3 64音频通道流

Orion32 HD是Orion家族的最新成员。兼容市场上任何DAW以及HDX端口或USB3,全新Pro Tools HD和本地接口提供一切Antelope Audio所支持的。64通道192 kHz音频I/O流,Antelope业界领先的时钟,以及原始AD/DA转换。 Orion32 HD的模拟I /O由8个DB25连接器处理,同时配备有MADI,ADAT和S /PDIF连接性。

Orion32 HD拥有精选的复古特效,由Antelope Audio的新型现场可编程门阵列(FPGA)进行技术提供,将传奇复古设备的模型提升至一个全新的水平。

功能

http://zh.antelopeaudio.com/wp-content/themes/salient/css/fonts/svg/arrows_expand.svg

64通道 I/O

通过HDX&USB3同时传输64 I / O通道24位,192 kHz音频

http://zh.antelopeaudio.com/wp-content/themes/salient/css/fonts/svg/basic_target.svg

顶级时钟

由Antelope的64位时钟技术与2字时钟或Loopsync输出,字时钟或LoopSync&Antelope 10M / 10MX原子钟输入

http://zh.antelopeaudio.com/wp-content/themes/salient/css/fonts/svg/arrows_keyboard_alt.svg

强大的FPGA

定制FPGA为多个显示器混音器和实时效果处理供电,经检测只有2个几乎听不到的延迟试样!

http://zh.antelopeaudio.com/wp-content/themes/salient/css/fonts/svg/music_shuffle_button.svg

优秀的监听输出

高级监控DA包括使用我们受欢迎的Pure2母带制作转换器的芯片

http://zh.antelopeaudio.com/wp-content/themes/salient/css/fonts/svg/basic_mixer2.svg

软件控制

路由,混音,实时效果处理和OS X&Windows兼容的应用程序

http://zh.antelopeaudio.com/wp-content/themes/salient/css/fonts/svg/music_mute.svg

扩展连接性

HDX, USB3, MADI, ADAT, S/PDIF, 8x DB25

Orion32 HD 功能

描述

速度与激情

平滑混音和优秀监听

像它的前辈一样,Orion32 HD是一个多功能的音频接口,与市场上任何DAW都可以完美搭配。它让你不仅可以在追踪时串流一个惊人的64通道音频,还允许多个监测混音。监控时,声音是令人愉快的,非常自然清透,就像 Antelope.所有的产品一样。独立软件混音器,集成的基于硬件的FPGA复古效果,全都具备,并拥有比以往更多的连接选项。

…it looks great, sounds fantastic, feels reliable and solid — everything a high end piece of studio gear should be”

Matt Vanacoro, one of New York’s premier musicians, he has collaborated as a keyboardist in studio and on stage with artists such as Jordan Rudess (Dream Theater), Mark Wood (Trans-Siberian Orchestra), Mark Rivera (Billy Joel Band), Aaron Carter and many more.

我们喜爱的时钟

完美的时钟,完美的声音

Orion32 HD无与伦比的时钟精度由Antelope著名的64位声聚焦时钟(AFC)抖动管理技术提供。Antelope的时钟以其卓越的稳定性和先进的声音享誉世界20年。瞬变前所未有的优秀,您将获得无与伦比的、深度和细节并存的立体声声象。

还有生成稀疏矩阵和清透的高频…是的,我们说的是完美的声音,正像我们划时代的OCX HD和Trinity主时钟。

FPGA技术支持

Orion32 HD包括精选的免费基于硬件的复古AFG

专属的FPGA是Antelope Audio所有产品接口的心脏和灵魂,这些Orion 32 HD都有。让你使用Antelope的集成和不断增长的基于硬件的复古EQ,压缩器和AuraVerb。 复古EQ的精美系列包括Lang PEQ1,BAE 1073,1084,1023,UK-69的真实模型和许多其他经典的英国和德国复古产品。复古压缩器始于理想的FET76模型,其他产品很快也会变为可用的,所有新用户的和注册用户可以免费使用Antelope系列的世界级接口。

发现所有关于羚羊音频硬件的复古效果,点击这里。

… it reacts right away, it shows exactly what you’re doing at the moment, there’s zero latency. And it’s a beautiful thing.”

Michael “Fish” Herring. An accomplished musician, Fish toured the world with artists from the unknown to the legendary. He has also appeared on records for artists such as Mariah Carey, Tupac, Nas, LeAnn Rimes, Siedah Garrett, Celine Dion and other superstars, as his discography continues to grow.

直观的软件控制

有了Orion 32 HD桌面应用程序,你最疯狂的路由梦成真了!

Orion32 HD易于操作,通过其直观的OS X和Windows可兼容的桌面应用程序。它的彩色编码路由矩阵现在具有另一种独特的视图,使路由变得更容易。可以从同一网络上的多台计算机访问该接口。随着可自由移动和可调整大小的面板,你可以最大限度地利用你的电脑监视空间,完全胜任巨大的工作项目,为电影配乐并支持多种屏幕。

google-play

教程

TUTORIALS coming soon…

Our content team is working on this. Check back in a couple of days.

连通性

Power Button
Oven Clock Light
LOCK Light
Atomic Clock Light
Frequency Buttons Up & Down
Display
Antelope Function Button
Preset Buttons 1 – 5
Main Power Connection
Word Clock Input
Atomic Clock Input
Word Clock Outputs
S/PDIF Output
S/PDIF Input
Monitor Outputs
HDX I/O
ADAT Input
ADAT Output
MADI I/O
USB 3
Analog Outputs D-SUB 25
Analog Inputs D-SUB 25

规格

    • ANALOG

      Analog Inputs
      4 x D-SUB 25 (32 channels total), +24 dBu max

      Analog Outputs
      4 x D-SUB 25 (32 channels total), +24 dBu max
      2 x Monitor Outs on TRS 1/4 Jacks, +24 dBu max

      D/A Monitor Converter
      Dynamic Range: 129 dB
      THD + N: -108 dB

      A/D Converter
      Dynamic Range: 120 dB
      THD + N: -110 dB

      D/A Converters
      Dynamic Range: 120 dB
      THD + N: -107 dB

    • DIGITAL

      Digital Inputs
      1 x Fiber Optic MADI (up to 64CH)
      2 x ADAT (up to 16CH)
      1 x S/PDIF

      Digital Outputs
      1 x Fiber Optic MADI (up to 64CH)
      2 x ADAT (up to 16CH)
      1 x S/PDIF

      USB 3.0 I/O
      USB 3.0 – 64 chennels I/O up to 192kHz,
      USB 3.0 Type B connector

      HDX Connectivity

      2 x mini HDX connectors for direct Pro Tools connection
      32 Channels I/O each ( total of 64 channels )

    • CLOCKING

      Word Clock Input
      1 x Input @ 75 Ohms 3Vpp on BNC 32 – 192kHz

      Atomic Clock Input
      1 x 10M Input @ 75 Ohms 1Vpp on BNC

      Word Clock Outputs
      2 x Outputs @ 75 Ohms 3Vpp on BNC 32 – 192kHz

      Clocking System
      4th Generation Acoustically Focused Clocking
      64-bit DDS
      Oven Controlled Crystal Oscillator

      Clock Stability
      <+/-0.02 ppm, oven controlled at 64.5ºC/ 148.1ºF

      Clock Aging
      < 1 ppm per year

      Clock Calibration
      < +/-0.001 ppm

      Sample Rates (kHz)
      32, 44.1, 48, 88.2, 96, 176.4, 192

    • OTHER

      Operating Temperature
      0-50°C, 32-122°F

      Weight
      3.6kg / 8.0 lb ( approx )

      Dimensions (Approx)
      Width: 483 mm / 19”
      Height: 44 mm / 1.75”
      Depth: 270mm / 10.63″

      Power Consumption
      30 Watts Max

Audio interfaces comparison table

 Orion32 HDGoliathZen TourOrion StudioOrion32+Zen StudioOrion32
Orion32 HDGoliathZen TourOrion StudioOrion32+Zen StudioOrion32
Analog InsertsN/A2 x Inserts on 1/4" TRS (dedicated for inputs 1, 2)N/A2 x Inserts on 1/4" TRS (dedicated for inputs 1, 2)N/A2 x Inserts on 1/4" TRS (dedicated for inputs 1, 2)N/A
Analog Inputs4 x DB 25 (32 channels total), +24 dBu max2 × DB25 (16 channels)
16 × Mic / Line on XLR combos (incl. 4 × Hi-Z)
4 × Hi-Z inputs on 1/4" TRS on front
4 × Mic / Line / Hi-Z on XLR combos
4 × Hi-Z / Line on 1/4" TRS
4 × Mic / Line / Hi-Z on XLR combos
8 × Mic / Line on XLR combos
4 x DB25 (32 channels total), +20 dBu max, 11.2 kOhms1 x DB25 (8 channels)
4 x Mic / Line / Hi-Z on XLR combos on the front
8 x Mic / Line on XLR combos on the rear
4 x DB25 (32 channels total), +20 dBu max, 11.2 kOhms
Analog Outputs4 x DB 25 (32 channels total), +24 dBu max
2 x Monitor Outs on TRS 1/4 Jacks, +24 dBu max
3 × DB25 (24 channels)
2 x Stereo Monitor outs on 1/4" TRS
2 × Stereo Headphone outs on 1/4" TRS
2 × ReAmp outs on 1/4" TRS
1 × DB25 (8 channels)
2 × Stereo Monitor outs on 1/4" TRS (4 channels, only 1 pair active at a time)
2 × Stereo Headphone outs on 1/4" TRS
2 × ReAmp outs on 1/4" TRS
2 × DB25 (16 channels)
2 × Stereo Monitor outs on 1/4" TRS (4 channels, only 1 pair active at a time)
2 × Stereo Headphone outs on 1/4" TRS
2 × ReAmp outs on 1/4" TRS
4 x DB25 (32 channels total), +20dBu, 56 Ohms
2 × Stereo Monitor outs on 1/4" TRS
1 x DB25 (8 channels)
1 x Stereo pair of Monitor outs on 1/4" TRS
2 x Stereo Headphone outs on 1/4" TRS (4 channels)
4 x DB25 (32 channels total), +20 dBu, 56 Ohms
Digital Inputs1 x Fiber Optic MADI (up to 64 channels)
2 x ADAT (up to 16 channels)
1 x S/PDIF
2 × Fiber Optic MADI (up to 64 channels each)
2 × ADAT (up to 16 channels)
1 × S/PDIF
8 × AES/EBU on DB25 (16 channels)
2 × ADAT optical (up to 16 channels)
1 × S/PDIF on RCA
2 × ADAT (up to 16 channels)
1 × S/PDIF
1 x Fiber Optic MADI (up to 64 channels)
2 x ADAT (up to 16 channels)
1 x S/PDIF
2 x ADAT (up to 16 channels)
1 x S/PDIF
1x Fiber Optic MADI (up to 64 channels)
2 x ADAT (up to 16 channels)
1x S/PDIF
Digital Outputs1 x Fiber Optic MADI (up to 64 channels)
2 x ADAT (up to 16 channels)
1 x S/PDIF
2 × Fiber Optic MADI (up to 64 channels each)
2 × ADAT (up to 16 channels)
1 × S/PDIF
8 × AES/EBU on DB25 (16 channels)
2 × ADAT optical (up to 16 channels)
1 × S/PDIF on RCA
2 × ADAT (up to 16 channels)
1 × S/PDIF
1 × Fiber Optic MADI (up to 64 channels)
2 × ADAT (up to 16 channels)
1 × S/PDIF
2 x ADAT (up to 16 channels)
1 x S/PDIF
1 × Fiber Optic MADI (up to 64 channels each)
2 × ADAT (up to 16 channels)
1 × S/PDIF
Thunderbolt™N/A1 × Thunderbolt™ (64 channels I/O)1 × Thunderbolt™ (32 channels I/O)1 × Thunderbolt™ (32 channels I/O)1 × Thunderbolt™ (64 channels I/O)N/AN/A
USBUSB 3.0 – 64 chennels I/O up to 192kHz, Type B connectorUSB 2.0 Hi-Speed; Data stream up to 480 Mbits/192kHz,
32 channels I/O, Type B
USB 2.0 Hi-Speed; Data stream up to 480 Mbits/192kHz,
24 channels I/O, Type B
USB 2.0 Hi-Speed; Data stream up to 480 Mbits/192kHz,
24 channels I/O, Type B
USB 2.0 Hi-Speed; Data stream up to 480 Mbits/192kHz,
32 channels I/O, Type B
USB 2.0 Hi-Speed; Data stream up to 480 Mbits/192kHz,
24 channels I/O, Type B
USB 2.0 Hi-Speed; Data stream up to 480 Mbits/192kHz,
32 channels I/O, Type B
HDX Connectivity2 x mini HDX connectors for direct Pro Tools connection
32 Channels I/O each ( total of 64 channels )
N/AN/AN/AN/AN/AN/A
Word Clock Input1 x Input @ 75 Ohms 3Vpp on BNC 32 – 192kHz1 × Input @ 75 Ohms on BNC 32 –192kHzN/A1 × Input @ 75 Ohms on BNC 32 –192kHz1 × Input @ 75 Ohms on BNC 32 –192kHz1 × Input @ 75 Ohms on BNC 32 –192kHz1 × Input @ 75 Ohms on BNC 32 –192kHz
Word Clock Output2 x Outputs @ 75 Ohms 3Vpp on BNC 32 – 192kHz2 × Outputs @ 75 Ohms on BNC 32 –192kHzN/A1 × Outputs @ 75 Ohms on BNC 32 –192kHz2 × Outputs @ 75 Ohms on BNC 32 –192kHz1 × Outputs @ 75 Ohms on BNC 32 –192kHz4 × Outputs @ 75 Ohms on BNC 32 –192kHz square wave signal
Atomic Clock Input1 x 10M Input @ 75 Ohms 1Vpp on BNC1 x 10MHz Input @ 75 Ohms 1Vpp on BNCN/AN/A1 × 10MHz Input @ 75 Ohms on BNCN/A1 x 10MHz Input @ 75 Ohms on BNC
D/A Monitor ConverterDynamic Range: 129 dB
THD + N: -108 dB
Dynamic Range: 129 dB;
THD + N: -108 dB
Dynamic Range: 129 dB
THD + N: -108 dB
Dynamic Range: 129 dB
THD + N: -108 dB
Dynamic Range: 129 dB
THD + N: -108 dB
Dynamic Range 118dB
THD + N -98dB
N/A
D/A ConverterDynamic Range: 120 dB
THD + N: -107 dB
Dynamic Range: 120 dB;
THD + N: -107 dB
Dynamic Range: 120 dB
THD + N: -107dB
Dynamic Range: 120 dB
THD + N: -107dB
Dynamic Range: 118 dB
THD + N: -98 dB
Dynamic Range 118dB
THD + N -98dB
Dynamic Range: 118dB
THD + N: -98 dB
A/D ConverterDynamic Range: 120 dB
THD + N: -110 dB
Dynamic Range: 120 dB;
THD + N: -110 dB
Dynamic Range: 120 dB
THD + N: -110 dB
Dynamic Range: 120 dB
THD + N: -110 dB
Dynamic Range: 118 dB
THD + N: -105 dB
Dynamic Range 118dB
THD + N -105dB
Dynamic Range 118dB
THD + N -105dB
Mic PreampN/AGain: 0, 10 – 65 dB
THD + N: -108 dB
Gain: 0 – 65 dB
THD + N: -108 dB
Gain: 0,10 – 65 dB
THD + N: -108 dB
N/AGain: 0,10 – 65dB
THD + N -108dB
N/A
Clocking system4th Generation Acoustically Focused Clocking
64-bit DDS
Oven Controlled Crystal Oscillator
4th Generation Acoustically Focused Clocking
64-bit DDS
Oven Controlled Crystal Oscillator
4th Generation Acoustically Focused Clocking
64-bit DDS
Oven Controlled Crystal Oscillator
4th Generation Acoustically Focused Clocking
64-bit DDS
Oven Controlled Crystal Oscillator
4th Generation Acoustically Focused Clocking
64-bit DDS
Oven Controlled Crystal Oscillator
4th Generation Acoustically Focused Clocking
64-bit DDS
Oven Controlled Crystal Oscillator
4th Generation Acoustically Focused Clocking
64-bit DDS
Oven Controlled Crystal Oscillator
Sample Rates32, 44.1, 48, 88.2, 96, 176.4, 192 (kHz)32, 44.1, 48, 88.2, 96, 176.4, 192 (kHz)32, 44.1, 48, 88.2, 96, 176.4, 192 (kHz)32, 44.1, 48, 88.2, 96, 176.4, 192 (kHz)32, 44.1, 48, 88.2, 96, 176.4, 192 (kHz)32, 44.1, 48, 88.2, 96, 176.4, 192 (kHz)32, 44.1, 48, 88.2, 96, 176.4, 192 (kHz)
Electrical SpecsAC Universal input: 95-245V
Power Consumption: 30 Watts Max.
AC Universal input: ~95-245 V
Power Consumption: 40 Watts Max
DC Universal input: 18V
Power Consumption: 25 Watts Max
DC Universal input: 18V
Power Consumption: 25 Watts Max
AC Universal input: ~95-245 V
Power Consumption: 20 Watts Max
DC Universal input: 18V
Power Consumption: 25 Watts Max
AC Universal input: 95-245V
Power Consumption: 20 Watts Max.
Physical SpecsDimensions: 483 mm/19” (W) / 44 mm/1.75” (H) / 220 mm/8.66” (D)
Weight: 3.6 kg/ 8.0 lbs approx.
Dimensions: 483 mm/19” (W) / 81 mm/3.2” (H) / 279 mm/11” (D)
Weight: 6.8 kg/ 15 lbs approx.
Dimensions: 25.5 mm/10” (W) / 5.9 mm/2.4” (H) / 16.6 mm/6.5” (D)
Weight: 1.4 kg/ 3.09 lbs
Dimensions: 483 mm/19” (W) / 44 mm/1.7” (H) / 220 mm/8.6” (D)
Weight: 3.1 kg/ 6.83 lbs
Dimensions: 483 mm/19” (W) / 44 mm/1.75” (H) / 220 mm/8.66” (D)
Weight: 3 kg/ 6.6 lbs approx.
Dimensions: 418 mm/16.8” (W) / 45 mm/1.8” (H) / 145 mm/5.8” (D)
Weight: 2 kg/4.41 lbs approx.
Dimensions: 483 mm/19” (W) / 44 mm/1.75” (H) / 220 mm/8.66” (D)
Weight: 3 kg/ 6.6 lbs approx.

System requirements

WINDOWS

OS: Windows 7/8/8.1/10
Disk Space: Minimum 512 MB available disk space
USB: 1x USB 3.0 Port
CPU: Intel or AMD equivalent CPU with at least 2GHz operating frequency
Memory (RAM): 4GB Minimum (8GB or more Recommended)

MAC

OS X: 10.9/10.10/10.11/10.12 (El Capitan 10.11.6 Recommended)
Disk Space: Minimum 512 MB available disk space
USB: 1x USB 3.0 Port
Thunderbolt: 1x Thunderbolt/USB-C Port
Memory(RAM): 4GB Minimum (8GB or more recommended)
CPU: Intel Core 2 Duo (Minimum) Intel Core i3 ™ or higher (Recommended)

Additional Info: Internet connection required for product activation.

评论

下载

SOFTWARE

Launchers

Windows
Download Orion Studio Launcher for Windows7 and newer (Jun 7, 2016)

MAC
Download Orion Studio Launcher for Mac OS X 10.9 and newer (Jun 7, 2016)

Remote Control Apps

Android
Android app remote for the Orion Studio

Apple
Apple app remote for the Orion Studio

Zen Studio+

Zen Studio+

Portable Thunderbolt™ and USB interface with 12 mic pres

Orion32 HD

Orion32 HD

64通道HDX & USB 3.0 AD/DA 接口

Orion Studio

Orion Studio

Thunderbolt ™ and USB 工作室介面

Goliath

Goliath

Thunderbolt ™, USB & MADI Audio Interface
